Pouzity vstrikolis Krauss Maffei KM 320-1000 C3 MC4

machine-no.: 502026 manufacturer: KRAUSS MAFFEI Typ: KM 320-1000 C3 MC4 year of construction: 2004 operating hours: 46669 h type of drive: vollhydraulisch clamping type: Vollhydraulik method of construction: vierholmig clamping force: 3200 kN distance between tie bars h: 710 mm distance between tie bars v: 710 mm size of mould plates h: 1060 mm size of mould plates v: 1055 mm min. mould height: 380 mm opening stroke: 920 mm ejector stroke: 250 mm ejector force: 95 kN centring device diameter of moving platen: 80 mm centring device diameter of fixed platen: 120 mm mould weight: 4780 kg screw diameter: 55 mm swept volume: 305 ccm injection pressure: 1904 bar screw length: 20 mm screw geometry: 9 screw rotation: 453 min plasticising rate: 428 g/s PS injection rate into the open: 65 g/s PS number of heating zones: 5 measures of machine lxbxh: 6.78m x 2.09m x 2.43m total weight: 15200KG • srew drive by three phase motor • DFEE Pump for parallel function of hydr.ejector and core pulling • pressure accumulator for uprated injection speed • Anti vibration mounts • Schuko-socket 10A • electric interface for handling units according to Euromap 12 • air valve fixed WAP • machine without material hopper • CEE-socket 16A • core pulling hydraulically 2x • screen text german • CEE-socket 32A Maschinenhandel Borowski GmbH, Germany [email protected]
